| Order No.
|
Product Description
|
| L45-Z00
|
LMG450 manual, German or English
|
| L45-Z01
|
19"-Mounting kit for LMG450
|
| L45-Z02
|
Carrying / tilting handle bar for LMG450
|
| L45-Z04
|
Carrying case for LMG450 and accessories
Plastic foam material inside, outside material Aluminum, lockable, dimensions 25cm x 49cm x 38cm
|
| L45-Z09
|
Adapter BNC to HD15 for isolating current sensors with voltage output; but no EEPROM
|
| L45-Z13
|
LMG450/500 master-slave cable, length 1m
connection of 2 pcs. LMG450 via Sync inputs for simultaneous measuring of more than 4 phases
Possible couplings:
LMG450 <-> LMG450
LMG450 <-> LMG500 (1-8 phase)
LMG500 (1-8 phase) <-> LMG500 (1-8 phase)
|
| L45-Z18
|
Adapter for incremental speed sensor onto LMG450 measuring channel (HD15 sensor input)
Pulses converted an analog voltage with +/- sign indicating sense of rotation
Short response time for graphical presentation to analyse extremely dynamic processes
|
| L45-Z22
|
Adapter safety plug to HD15 for isolating current sensors
with current output up to 1,2Apk; EEPROM for storage of scaling
|
| L45-Z318
|
RS232 - Ethernet - converter, 10/100Mbit
external adaptor, all connectors will fixed at the LMG, power supply from LMG
|
| SSU4
|
Supply unit for 1 to 4 pcs. PSU600 sensors and L45-Z29,
for use with LMG instruments
|
| LMG-Z-AMP
|
Artificial starpoint simulation for 3p-3w-systems
|
| L5-Z03
|
Cable for coupling of process signal interfaces (analogue and digital) between two LMG450 and/or LMG95
(option L45-O3, L95-O3), exchange of measuring values for further computation with formula editor, e.g. calculation of efficiency
|
| L5-IOBOX-S
|
Adapter (also for DIN rail mount) from 25pol. SUB-D connector to screw cage connection for conductor cross sections up to 1,5mm x mm
incl. 2m cable for connecting adapter with one processing signal interface
|
| L5-IOBOX-F
|
Adapter (also for DIN rail mount) from 25pol. SUB-D connector to screw cage connection for conductor cross sections up to 1,5mm x mm
incl. 2m cable for connecting adapter with one processing signal interface
|
